Pylon sign design
The sign that works the road
A pylon earns its keep in the two or three seconds a driver gives it at speed, and that reality drives every design decision: letter heights sized to the read distance, tenant panels ordered so the anchor reads first, contrast that survives a bright sky behind it, and a cabinet shape that still says something when the driver is past it.
We design the sign and draw the set that gets it approved and built. We don't fabricate or install, so the set is spec-driven and any qualified shop can bid it. It's one branch of our exterior signage work.
Height and area to code
The calculations the ordinance caps, worked out and shown so the reviewer checks them instead of redoing them.
Structure and footing coordination
Pole, cabinet, and footing coordinated for the PE, with the stamp requirement flagged before it stalls a permit.
Electrical and service access
Power stub-out, disconnect, and service access drawn in, because a lit sign nobody can service is a warranty call.
Materials and illumination
Cabinet construction, faces, and lighting specified so fabrication bids price the same sign.
Who we work with
Sign companies
White-label design and documentation for shops busy building. We draw, you fabricate, and your client never knows we were involved.
Architects & designers
Signage and wayfinding documented to sit inside your set, on your schedule, drawn to the standard the rest of your drawings hold.
Facilities & property teams
Wayfinding and sign standards for campuses, portfolios, and multi-building sites that have outgrown the signs they started with.
Brands & retailers
Sign programs that hold the brand across every location and bend to each local code, without ever losing the look you built.
Pylon signs, answered
Didn't find your question? Ask us directly — straight answers, no runaround.
- How tall can a pylon sign be?
- As tall as the local code allows, which is the honest answer. Freeway-oriented districts might allow 45 to 85 feet, a suburban commercial corridor might cap you at 20, and some jurisdictions have phased pylons out entirely in favor of monuments. We check the ordinance before the first sketch so nobody falls in love with a sign the city won't approve.
- Pylon or monument, which does my site need?
- Speed and distance decide it. If your customer finds you at highway speed, the sign needs height, and that's a pylon. If they find you from the street at 25 miles an hour, a monument reads better, costs less to build, and clears review more easily. Some codes make the call for you by capping height.
- What drives the cost of a pylon?
- Height, wind load, and dirt. The sign everyone sees is a fraction of the structure: the steel inside the pole and the concrete footing under it are engineered to hold the whole thing up in a design-level windstorm, and they scale fast with height. Our drawings spec the visible sign completely and coordinate the structure so the engineering doesn't start from a napkin.
- Does a pylon sign need an engineer?
- Almost always. Most jurisdictions require a licensed structural engineer's stamp on the footing and structure for a sign this tall. We draw the set to the point a PE can review and seal it, and we coordinate with your engineer or one we work with.
